Ford Towing Guide

When you have a major job that needs to be done, you need a vehicle that's up to the task. In many cases, that means a vehicle capable of towing thousands of pounds. For a job like this, you can count on a reliable Ford to do all your heavy pulling.

We feature two kinds of Ford trucks capable of such a feat here at Ray Price Stroud, the F Series and the Transit Series. In order to help you decide which model is the most well-equipped for your task, we've created a Ford towing guide, which includes two helpful charts displaying the towing capacity and payload capacity of each model in both the F Series and the Transit Series for your reference.

F Series Towing Capacity and Payload Capacity

The following chart outlines the Ford F Series towing capacity, as well as the payload capacity of each model. The towing capacity is how much weight the vehicle can tow behind it, while the payload capacity is the maximum weight of the entire haul it can handle, including the occupants of the vehicle. The capacities are expressed as a weight range rather than a set weight because additional features of each model, such as engine and axle types, also affect how much the vehicle can haul.

Model and Towing Type

Towing Capacity

Payload Capacity

F-150 conventional

5,000-12,200 lb.

9,400-17,100 lb.

F-150 5th-wheel

4,900-12,100 lb.

9,400-17,100 lb.

F-250 SRW Super Duty conventional

12,300-17,600 lb.

19,500-25,700 lb.

F-250 SRW Super Duty 5th-wheel/Gooseneck

12,200-18,500 lb.

19,500-25,700 lb.

F-350 SRW Super Duty conventional

12,000-18,000 lb.

19,500-28,700 lb.

F-350 SRW Super Duty 5th-wheel/Gooseneck

12,000-21,500 lb.

19,500-28,700 lb.

F-350/450 DRW Super Duty conventional

12,100-21,000 lbs./21,000 lb.

20,000-40,000/41,800 lb.

F-350/450 DRW Super Duty 5th-wheel/Gooseneck

12,300-32,000/32,500 lb.

20,000-40,000/41,800 lb.

F-350/450/550 Super Duty Chassis conventional

12,200-18,500 lb.

19,500-40,000 lb.

F-350/450/550 Super Duty Chassis 5th-wheel

12,200-31,800 lb.

19,500-40,000 lb.

Transit Series Towing Capacity and Payload Capacity

The chart below outlines the Transit Series towing capacity. Again, the capacity is expressed as a range due to the fact that additional features of each vehicle affect how much it is capable of towing. The overall payload capacity for the models in the Transit Series is between 10,800 and 13,500 pounds.


Towing Capacity

Transit 150/250 Van

4,500-7,500 lb.

Transit 250 Van

4,200-7,300 lb.

Transit 350 Van

4,200-7,100 lb.

Transit 150 Wagon

4,500-51,000 lb.

Transit 350 Wagon

2,900-4,700 lb.

Transit 250 Cutaway/Chassis

6,600-7,500 lb.

Transit 350 Cutaway/Chassis

6,200-7,500 lb.

Take a Test Drive Today!

Hopefully our Ford towing guide has provided you with a better understanding of which model is up to the work that lies ahead. Now that you're a bit more familiar with the F Series towing capabilities and the Transit towing capabilities, it's time to take a test drive at your local Ford dealer in Stroudsburg, Pennsylvania. Contact us today at Ray Price Stroud Ford to schedule your appointment. We look forward to working with you!
